Airtac TSAIM Cylinder with Guide Bracket TSAIM100X250
1. The TSAIM series represents an innovative integration of a guide frame and cylinder, delivering enhanced structural stability and functional versatility.
2. Bearing options optimized for diverse applications:
- Slide bearings: Engineered for radial load resistance in braking scenarios, offering superior torsional rigidity.
- Linear bearings: Ideal for pushing/lifting operations requiring high precision, heavy load capacity, and minimal friction applications.
3. Multi-axis mounting configurations enabled by the guide frame's proprietary design, ensuring flexible installation adaptability.
4. Precision cushioning adjustment system guarantees smooth stroke termination and operational stability.
5. Modular sensor mounting base allows positional customization to meet diverse sensing requirements.
Category: Guide Rod Cylinders | Brand: AirTAC | Series: TSAIM
AirTAC TSAIM100X250 Guided Cylinder Specifications
- Model: TSAIM100X250
- Type: Guided rod cylinder with precision linear bearings
- Bore size: Ø100 mm
- Stroke: 250 mm
- Operating pressure: 0.05–1.0 MPa
- Piston speed: 50–800 mm/s
- Cushioning: Adjustable pneumatic cushion (both ends)
- Mounting style: Front flange MF1 / Foot mounting MF5 (optional)
- Rod end thread: M30×1.5 (male)
- Seal material: NBR + polyurethane hybrid seals
- Temperature range: -10℃ to 80℃
- Weight: 22.5 kg ±3%
- Dimensions: 580mm(L) × 150mm(W) × 120mm(H)
- Guide mechanism: Dual linear ball bearings with 4 rails
- Lubrication: Pre-lubed (Grease-free operation available)
- Port size: G3/8 (NPT1/2 optional)
Heavy-duty guided cylinder engineered for high moment load resistance and precise linear motion. Features anti-rotation design with hardened guide rails, capable of handling 2.5× higher side loads compared to standard cylinders. The integrated wiper system prevents particulate ingress in harsh environments.
- Automated palletizing systems with lateral forces
- Precision glass panel handling robots
- Die-casting machine ejection mechanisms
- Automotive welding fixture positioning
- PCB press-fitting equipment
Installation note:
Requires torque-controlled tightening (35-40 N·m for mounting bolts).
Maintain 0.5mm minimum clearance between guide rails and adjacent components.
Lubricate guide rails every 500km of travel using ISO VG32 hydraulic oil.
| Property | Property Value |
|---|---|
| sku | TSAIM100X250 |
| Port Size | PT 1/2 |
| Bore Diameter | 100mm |
