Airtac TSAIM Cylinder with Guide Bracket TSAIM100X400
1. The TSAIM series represents an innovative integration of a guide frame and cylinder, delivering enhanced structural stability and functional versatility.
2. Bearing options optimized for diverse applications:
- Slide bearings: Engineered for radial load resistance in braking scenarios, offering superior torsional rigidity.
- Linear bearings: Ideal for pushing/lifting operations requiring high precision, heavy load capacity, and minimal friction applications.
3. Multi-axis mounting configurations enabled by the guide frame's proprietary design, ensuring flexible installation adaptability.
4. Precision cushioning adjustment system guarantees smooth stroke termination and operational stability.
5. Modular sensor mounting base allows positional customization to meet diverse sensing requirements.
Category: Guide Rod Cylinders | Brand: AirTAC | Series: TSAIM
AirTAC TSAIM100X400 Guided Rod Cylinder Specifications
- Model: TSAIM100X400
- Type: Double-acting guided cylinder with precision linear guides
- Bore size: 100mm
- Stroke: 400mm (±0.5mm tolerance)
- Operating pressure: 0.05–1.0 MPa
- Piston speed: 50–800 mm/s
- Mounting type: Front flange (MF1) with 4x M10x1.5 mounting holes
- Port size: G3/8 (BSPP thread)
- Guide mechanism: 4-row ball bearing system
- Maximum side load capacity: 1,800N
- Rod material: Hard chrome-plated SCM435 steel
- Seal material: NBR/Special urethane hybrid
- Temperature range: -10℃ to 80℃
- Weight: 12.5kg (without accessories)
- Dimensions: 640mm(L) × 150mm(W) × 148mm(H)
- Protection rating: IP67 (wipers included)
- Lubrication: Pre-lubricated (Grease-free operation)
Heavy-duty guided cylinder featuring integrated linear guides that eliminate rotational movement, designed for precision alignment applications. The hardened steel guide rails and dual-seal system ensure stable operation under high moment loads. Includes magnetic piston for position sensing compatibility.
- Precision press tooling alignment systems
- Automated welding fixture positioning
- Die-casting machine ejection mechanisms
- LCD panel handling robots
- Automotive wheel hub assembly stations
Installation note:
Requires parallel alignment within 0.2mm/m during mounting. Use only with guided cylinder-specific brackets (A6HZ series recommended). Lubricate guide rails with ISO VG32 hydraulic oil every 500km of travel.
| Property | Property Value |
|---|---|
| sku | TSAIM100X400 |
| Port Size | PT 1/2 |
| Bore Diameter | 100mm |
