Airtac TSAIM Cylinder with Guide Bracket TSAIM100X450
1. The TSAIM series represents an innovative integration of a guide frame and cylinder, delivering enhanced structural stability and functional versatility.
2. Bearing options optimized for diverse applications:
- Slide bearings: Engineered for radial load resistance in braking scenarios, offering superior torsional rigidity.
- Linear bearings: Ideal for pushing/lifting operations requiring high precision, heavy load capacity, and minimal friction applications.
3. Multi-axis mounting configurations enabled by the guide frame's proprietary design, ensuring flexible installation adaptability.
4. Precision cushioning adjustment system guarantees smooth stroke termination and operational stability.
5. Modular sensor mounting base allows positional customization to meet diverse sensing requirements.
Category: Guide Rod Cylinders | Brand: AirTAC | Series: TSAIM
AirTAC TSAIM100X450 Guided Rod Cylinder Specifications
- Model: TSAIM100X450
- Type: Double-acting guided cylinder with precision linear guides
- Bore size: 100mm
- Stroke: 450mm (±0.5mm tolerance)
- Operating pressure: 0.1–0.9 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Mounting style: Front/rear flange (ISO 15552 standard)
- Guide mechanism: Dual-axis hardened steel rods (Ø20mm)
- Port size: G3/8 (NPT1/2 optional)
- Seal material: NBR (HNBR available for high-temp)
- Temperature range: -10℃ to 80℃
- Protection rating: IP54 (standard wipers)
- Weight: 15.8kg (without accessories)
- Dimensions: 730mm(L) × 150mm(W) × 160mm(H)
- Max lateral load: 1,650N
- Max moment load: 1,100N·m
- Piston speed: 50–800mm/s
Heavy-duty guided cylinder engineered for precision linear motion under high moment loads. Features integrated chromium-plated guide rods with ball bushings for enhanced rigidity and anti-rotation performance. The dual-cushion design minimizes end-impact vibration, while the aluminum alloy body ensures optimal heat dissipation. Requires ISO VG32 hydraulic oil lubrication for guide rails.
- Automated palletizing systems
- Die-casting machine ejection mechanisms
- Precision glass panel handling
- Automotive welding fixture positioning
- CNC rotary table clamping
Installation note:
Maintain 0.05mm/m alignment tolerance during mounting.
Apply Molykote G-5007 grease to guide rods every 500km of travel.
Avoid side-load connections exceeding 30% of max capacity.
| Property | Property Value |
|---|---|
| sku | TSAIM100X450 |
| Port Size | PT 1/2 |
| Bore Diameter | 100mm |
