Airtac TSAIM Cylinder with Guide Bracket TSAIM100X50S
1. The TSAIM series represents an innovative integration of a guide frame and cylinder, delivering enhanced structural stability and functional versatility.
2. Bearing options optimized for diverse applications:
- Slide bearings: Engineered for radial load resistance in braking scenarios, offering superior torsional rigidity.
- Linear bearings: Ideal for pushing/lifting operations requiring high precision, heavy load capacity, and minimal friction applications.
3. Multi-axis mounting configurations enabled by the guide frame's proprietary design, ensuring flexible installation adaptability.
4. Precision cushioning adjustment system guarantees smooth stroke termination and operational stability.
5. Modular sensor mounting base allows positional customization to meet diverse sensing requirements.
Category: Guide Rod Cylinders | Brand: AirTAC | Series: TSAIM
AirTAC TSAIM100X50S Guided Rod Cylinder Technical Details
- Model: TSAIM100X50S
- Type: Double-acting guided cylinder with integrated linear guide
- Bore size: 100mm
- Stroke: 50mm
- Operating pressure: 0.1-0.9 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Mounting style: Basic type (MF1) with multiple optional configurations
- Port size: 1/2" NPT (G1/2 optional)
- Piston rod thread: M20×1.5
- Guide frame material: Anodized aluminum alloy (AL6063-T5)
- Seal material: Nitrile rubber (NBR) with wear-resistant ring
- Temperature range: -20℃ to 80℃
- Weight: 5.8kg (excluding accessories)
- Dimensions: 300mm(L) × 180mm(W) × 130mm(H)
- Protection rating: IP40 (dust protected)
- Max lateral load capacity: 1500N
- Max moment tolerance: 350N·m
Heavy-duty guided cylinder combining pneumatic actuation with precision linear guidance, designed for applications requiring exceptional moment resistance and alignment stability. Features dual hardened guide rails (HRC50+) with adjustable preload and four-row ball bearing system for smooth linear motion. Includes built-in magnet for position sensing compatibility.
- Automated assembly with side-load requirements
- Material handling systems with rotational forces
- Press-fit operations in automotive manufacturing
- Precision stamping equipment
- Vertical lifting mechanisms with guided alignment
- Packaging machinery with rotational tooling heads
Installation requirements:
Requires parallel alignment within 0.1mm/m tolerance. Lubricate guide rails with ISO VG32 hydraulic oil before initial operation.
Maximum recommended speed: 500mm/s. Periodic re-torque of guide block bolts (18N·m) required every 500km of travel.
| Property | Property Value |
|---|---|
| sku | TSAIM100X50S |
| Port Size | PT 1/2 |
| Bore Diameter | 100mm |
