Airtac TSAIM Cylinder with Guide Bracket TSAIM32X150S
1. The TSAIM series represents an innovative integration of a guide frame and cylinder, delivering enhanced structural stability and functional versatility.
2. Bearing options optimized for diverse applications:
- Slide bearings: Engineered for radial load resistance in braking scenarios, offering superior torsional rigidity.
- Linear bearings: Ideal for pushing/lifting operations requiring high precision, heavy load capacity, and minimal friction applications.
3. Multi-axis mounting configurations enabled by the guide frame's proprietary design, ensuring flexible installation adaptability.
4. Precision cushioning adjustment system guarantees smooth stroke termination and operational stability.
5. Modular sensor mounting base allows positional customization to meet diverse sensing requirements.
Category: Guide Rod Cylinders | Brand: AirTAC | Series: TSAIM
AirTAC TSAIM32X150S Guided Rod Cylinder Specifications
- Model: TSAIM32X150S
- Type: Double-acting guided cylinder with precision linear bearings
- Bore size: 32mm
- Stroke: 150mm (±0.5mm tolerance)
- Operating pressure: 0.15–0.8 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Mounting style: Front flange (MF1) & base mounting options
- Guide mechanism: 2 chrome-plated steel rods with 4 linear ball bushings
- Rod material: SCM435 steel with hard chrome plating (3-5μm)
- Seal material: NBR (nitrile) with wear-resistant ring
- Temperature range: -20℃ to 80℃
- Lubrication: Pre-lubricated (ISO VG32 equivalent)
- Weight: 2.45kg (excluding accessories)
- Dimensions: 300mm(L) × 80mm(W) × 85mm(H) (at mid-stroke)
- Guide load capacity: Max 1,500N radial force / 120Nm moment
- Protection rating: IP65 (wipers included)
- Piston speed: 50–700mm/s (optimal range)
High-rigidity guided cylinder featuring dual-axis anti-rotation design for precision linear motion. The hardened guide rods and ball bushings provide exceptional moment resistance while maintaining smooth operation. Integrated mounting slots allow flexible installation in multi-axis systems. Requires 40μm filtered air with ≤1mg/m³ oil content.
- Precision press-fit operations in automotive assembly
- Vertical lifting mechanisms for robotic end effectors
- Palletizing robot wrist axis actuation
- Glass panel transfer systems with anti-twist requirements
- Semiconductor wafer handling equipment
Installation note:
Align guide rods within 0.2mm/m parallelism tolerance. Apply M3 mounting screws
with 3.5N·m torque using cross-tightening sequence. Perform 50 break-in cycles
at 0.3MPa before full-load operation.
| Property | Property Value |
|---|---|
| sku | TSAIM32X150S |
| Port Size | PT1/8 |
| Bore Diameter | <32 mm> |
