Airtac TSAIM Cylinder with Guide Bracket TSAIM32X200S
1. The TSAIM series represents an innovative integration of a guide frame and cylinder, delivering enhanced structural stability and functional versatility.
2. Bearing options optimized for diverse applications:
- Slide bearings: Engineered for radial load resistance in braking scenarios, offering superior torsional rigidity.
- Linear bearings: Ideal for pushing/lifting operations requiring high precision, heavy load capacity, and minimal friction applications.
3. Multi-axis mounting configurations enabled by the guide frame's proprietary design, ensuring flexible installation adaptability.
4. Precision cushioning adjustment system guarantees smooth stroke termination and operational stability.
5. Modular sensor mounting base allows positional customization to meet diverse sensing requirements.
Category: Guide Rod Cylinders | Brand: AirTAC | Series: TSAIM
AirTAC TSAIM32X200S Guided Rod Cylinder Specifications
- Model: TSAIM32X200S
- Bore size: Ø32mm
- Stroke: 200mm
- Operating pressure: 0.05–1.0 MPa
- Operating temperature: -20℃ to 80℃
- Port size: M5×0.8 (dual ports)
- Cushioning: Adjustable pneumatic cushion
- Guide type: Dual-axis precision linear guide
- Rod material: Hard chrome-plated steel
- Cylinder tube: Aluminum alloy with hard anodizing
- Seal material: NBR/PU hybrid seals
- Repeat positioning accuracy: ±0.05mm
- Weight: 3.8kg (with standard accessories)
- Dimensions: 396mm(L) × 62mm(W) × 62mm(H)
- Mounting: Standard ISO 15552 front flange
- Protection rating: IP54 (standard wiper seal)
High-precision guided cylinder with integrated linear bearings, designed for applications requiring exceptional lateral load capacity and anti-rotation stability. Features dual-axis guidance system that reduces moment loads by 85% compared to standard cylinders. Pre-lubricated for maintenance-free operation up to 3,000km travel distance.
- Precision alignment in semiconductor handling robots
- Vertical lifting mechanisms for automated assembly lines
- High-moment load applications in glass panel transfer systems
- Precision pressing operations in electronic component manufacturing
- Multi-axis positioning systems requiring anti-torsion stability
Installation note:
Maintain parallel alignment within 0.1mm/m between guide rails and load path.
Use only with guided actuator brackets (AIRTAC GMB series recommended).
Lubricate guide shafts with ISO VG32 hydraulic oil every 5 million cycles.
| Property | Property Value |
|---|---|
| sku | TSAIM32X200S |
| Port Size | PT1/8 |
| Bore Diameter | <32 mm> |
