Airtac TSAIM Cylinder with Guide Bracket TSAIM32X250
1. The TSAIM series represents an innovative integration of a guide frame and cylinder, delivering enhanced structural stability and functional versatility.
2. Bearing options optimized for diverse applications:
- Slide bearings: Engineered for radial load resistance in braking scenarios, offering superior torsional rigidity.
- Linear bearings: Ideal for pushing/lifting operations requiring high precision, heavy load capacity, and minimal friction applications.
3. Multi-axis mounting configurations enabled by the guide frame's proprietary design, ensuring flexible installation adaptability.
4. Precision cushioning adjustment system guarantees smooth stroke termination and operational stability.
5. Modular sensor mounting base allows positional customization to meet diverse sensing requirements.
Category: Guide Rod Cylinders | Brand: AirTAC | Series: TSAIM
AirTAC TSAIM32X250 Guided Rod Cylinder Specifications
- Model: TSAIM32X250
- Type: Double-axis guided cylinder with integrated linear guide
- Bore size: 32mm
- Stroke: 250mm (customizable 25-500mm)
- Mounting style: Front flange (MF1) with optional side mounts
- Operating pressure: 0.1-0.9 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Piston speed: 50-800 mm/s
- Temperature range: -20℃ to 80℃
- Seal material: NBR (Nitrile rubber)
- Rod material: Hard chrome-plated steel
- Body material: Aluminum alloy (anodized)
- Guide rail type: Precision ground steel with wear-resistant coating
- Weight: 3.5kg ±2% (without accessories)
- Dimensions: 400mm(L) × 100mm(W) × 80mm(H)
- Port size: M5x0.8 (standard), G1/8 optional
- Lubrication: Pre-lubricated (Grease-free operation)
- Repeat positioning accuracy: ±0.05mm
- Maximum side load capacity: 800N
High-rigidity guided cylinder engineered for precision linear motion with exceptional moment resistance. The dual-axis guide structure eliminates rotation during stroke movement, making it ideal for vertical installations and applications requiring precise alignment. Features integrated scraper seals for contaminant protection.
- Precision press-fitting operations in automotive assembly
- Vertical lifting mechanisms for robotic arms
- Glass panel handling systems requiring anti-rotation
- High-speed sorting equipment with side load demands
- Semiconductor wafer transfer modules
Installation note:
Ensure guide rails are parallel within 0.1mm/m tolerance during mounting.
Use only with clean, dry air (ISO 8573-1:2010 Class 2.4.2).
Lubricate guide shafts monthly with ISO VG32 hydraulic oil in continuous operation.
| Property | Property Value |
|---|---|
| sku | TSAIM32X250 |
| Port Size | PT1/8 |
| Bore Diameter | <32 mm> |
