Airtac TSAIM Cylinder with Guide Bracket TSAIM32X250S
1. The TSAIM series represents an innovative integration of a guide frame and cylinder, delivering enhanced structural stability and functional versatility.
2. Bearing options optimized for diverse applications:
- Slide bearings: Engineered for radial load resistance in braking scenarios, offering superior torsional rigidity.
- Linear bearings: Ideal for pushing/lifting operations requiring high precision, heavy load capacity, and minimal friction applications.
3. Multi-axis mounting configurations enabled by the guide frame's proprietary design, ensuring flexible installation adaptability.
4. Precision cushioning adjustment system guarantees smooth stroke termination and operational stability.
5. Modular sensor mounting base allows positional customization to meet diverse sensing requirements.
Category: Guide Rod Cylinders | Brand: AirTAC | Series: TSAIM
AirTAC TSAIM32X250S Guided Cylinder with Guide Frame Specifications
- Model: TSAIM32X250S
- Type: Double-acting guided cylinder with integrated linear guide
- Bore size: 32mm
- Stroke: 250mm
- Operating pressure: 0.05–1.0 MPa
- Medium temperature: -20℃ to 80℃
- Cushion type: Adjustable rubber buffer (both ends)
- Guide load capacity: 1,500N (radial), 1,000N (moment)
- Repeat positioning accuracy: ±0.05mm
- Mounting style: Horizontal/vertical with 4x M6 threaded holes
- Port size: G1/8 (ISO228 standard)
- Piston rod thread: M16×1.5
- Material: Aluminum alloy body, hardened steel guide rails
- Seal material: NBR + PU hybrid seals
- Protection rating: IP54 (standard), IP67 optional
- Weight: 4.2kg (excluding accessories)
- Dimensions: 450mm(L) × 120mm(W) × 150mm(H)
High-rigidity guided cylinder featuring dual-axis linear motion guidance with 4-row ball bearing system. Engineered for applications requiring precise linear motion under high lateral loads or torque stresses. Anti-corrosion treatment on exposed surfaces with optional magnetic sensor slots (model variant available). Requires ISO 8573-1:2010 Class 3 compressed air.
- Precision press-fit operations in automotive assembly
- Vertical lifting mechanisms for robotic palletizers
- High-accuracy positioning in semiconductor handling
- Metal stamping die cushion systems
- Automated welding fixture alignment
Installation note:
Lubricate guide rails with ISO VG32 hydraulic oil before initial operation.
Maintain 0.5mm minimum clearance between guide frame and adjacent components.
Alignment tolerance: ≤0.1mm/m.
| Property | Property Value |
|---|---|
| sku | TSAIM32X250S |
| Port Size | PT1/8 |
| Bore Diameter | <32 mm> |
