Airtac X-AFD Swivel Adjustable Hex Port Connector X-AFD6
AirTAC X-AFD6 Swivel Adjustable Hex Tee Fitting Technical Details
- Model: X-AFD6
- Type: 360° rotatable & angle-adjustable 6-way connector
- Body material: Nickel-plated brass (standard) / Nylon optional
- Port configuration: 6 × 1/8" NPT(F) ports with swivel joints
- Max working pressure: 0.1-0.8 MPa (14.5-116 PSI)
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Seal material: HNBR (Hydrogenated Nitrile) for high temp resistance
- Rotation torque: ≤0.3 N·m at 0.6 MPa
- Leakage rate: <5 bubbles/min under ISO 6953-2 test
- Weight: 118±2g (brass version) / 46±1g (nylon version)
- Dimensions: 38mm (W) × 38mm (D) × 52mm (H)
- Surface treatment: Electroless nickel plating (≥12μm thickness)
- Compliance: RoHS 2.0 compliant
Multi-axis pneumatic distribution block enabling dynamic flow direction adjustments in compact spaces. Features tool-free 360° rotation with 15° incremental locking positions (24 detent points). Anti-vibration design maintains seal integrity under mechanical stress. Compatible with ISO 15407-1 pneumatic tubing standards.
- Robotic arm end-effector pneumatic circuits
- Modular automation test benches requiring quick reconfiguration
- Medical device pneumatic manifolds needing sterilization resistance
- Plastic injection molding machine air distribution
- Food processing equipment with frequent line changes
Installation protocol:
Apply PTFE tape on threads with 1.5 clockwise wraps. Tighten using 12mm hex key with
maximum 2.5 N·m torque. For nylon versions, avoid UV exposure and chemical solvents.
Perform pressure test at 1.25× operating pressure after installation.
