Airtac X-APDJ Insert Type Tee Adapter X-APDJ1206
AirTAC X-APDJ1206 Insertion Tee Fitting Technical Details
- Model: X-APDJ1206
- Type: Push-in tee connector (three-way)
- Thread specification: G1/8 (ISO228 standard)
- Material: Nickel-plated brass body + PPS plastic sleeve
- Operating pressure: 0.05-1.0 MPa
- Temperature range: -5℃ to 80℃ (non-freezing environment)
- Tube compatibility: Ø4mm, Ø6mm, Ø8mm polyurethane/nylon tubing
- Seal material: NBR (Nitrile) O-rings
- Weight: 18.5g ±0.3g
- Dimensions: 25.8mm(L) × 21.4mm(W) × 34.6mm(H)
- Vibration resistance: ≤10Hz @ 2.5mm amplitude
- IP rating: IP54 (when properly installed)
Multi-directional pneumatic connector featuring tool-free tube insertion and 360° rotatable ports. The anti-vibration locking mechanism prevents accidental disconnection, with color-coded plastic sleeves (blue standard) for quick circuit identification. Compatible with ISO 8434-1/DIN 3865 standards.
- Branch line connections in modular pneumatic systems
- Robotic arm end effector air supply distribution
- CNC machine tool pneumatic circuit splitting
- Medical equipment gas line manifolds
- Packaging machine air brake systems
Installation guide:
Cut tubing ends square, insert fully until "click" sound. For high-vibration environments,
apply thread sealant on male threads (PTFE tape not recommended). Maximum recommended
torque: 1.2N·m. Replace O-rings every 5,000 operating cycles in continuous use.
| Property | Property Value |
|---|---|
| sku | X-APDJ1206 |
