Airtac X-APDJ Insert Type Tee Adapter X-APDJ604
$3.43
Regular price
$10.93
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
X-APDJ604
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC X-APDJ604 Push-in Tee Fitting Technical Details
- Model: X-APDJ604
- Type: Insertion-type tee connector (T-port)
- Material: Brass with nickel plating (corrosion resistant)
- Port size: 1/4" NPT (parallel thread ISO G1/4 optional)
- Tube compatibility: Ø6mm (1/4") OD pneumatic tubing
- Operating pressure: 0.05-1.0 MPa
- Temperature range: -20℃ to 80℃
- Seal material: HNBR (hydrogenated nitrile) for improved oil resistance
- Insertion force: ≤35N (with lubrication)
- Extraction force: 60-80N (tube removal collar required)
- Weight: 28g ±1g
- Dimensions: 20mm(L) × 15mm(W) × 15mm(H) (body only)
- Vibration resistance: 10-2000Hz, 20m/s² max
- IP rating: IP40 (protected against tool access)
High-flow tee connector with tool-free installation design, featuring 360° rotatable ports for flexible piping arrangements. The internal flow channel is precision machined to minimize pressure drop (ΔP ≤0.01MPa @1.0MPa). Compatible with PU, nylon, and polyethylene tubing.
Primary Applications:
- Branch line creation in pneumatic automation systems
- Modular assembly in packaging machinery air circuits
- Sensor air supply distribution networks
- Medical device pneumatic manifold systems
- Robotic end-effector air routing
Installation protocol:
Cut tubing square (90°±2° tolerance), insert fully until audible click.
For maintenance, use AirTAC ST-06 tube removal tool.
Recommended torque: 1.2-1.5Nm during threaded port assembly.
Not compatible with PTFE tubing or hydraulic fluids.
Max allowable lateral load: 15N.
Perform leakage test at 0.8MPa after installation.
| Property | Property Value |
|---|---|
| sku | X-APDJ604 |
