Airtac X-APDT Adapter - Full Brass Threaded Side Tee X-APDT401
$5.28
Regular price
$12.78
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
X-APDT401
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC X-APDT401 Full Brass Threaded Side Tee Fitting Specifications
- Model: X-APDT401
- Material: Lead-free brass (RoHS compliant)
- Thread type: Metric parallel thread (M5×0.8)
- Port configuration: 3-way T-shaped flow path
- Operating pressure: 0.05-1.0 MPa
- Temperature range: -5℃ to 80℃
- Surface treatment: Electroplated nickel (3-5μm thickness)
- Seal type: Integrated O-ring (NBR material)
- Proof pressure: 1.5 MPa
- Weight: 12.5±0.3g
- Dimensions: 16mm (H) × 16mm (W) × 16mm (L)
- Vibration resistance: 10-55Hz, 1.5mm amplitude
- Certifications: ISO 8434-1, DIN 2353 standards
Precision-machined brass tee connector featuring corrosion-resistant nickel plating and integrated sealing. The compact cube design enables space-saving installation in complex pneumatic circuits. Three M5×0.8 ports allow 360° rotational adjustment during assembly.
Typical Applications:
- Branch line connections in pneumatic control systems
- Modular assembly of automation equipment manifolds
- Pressure gauge mounting configurations
- Air tool pneumatic distribution blocks
- Medical gas line distribution junctions
Installation note:
Apply 2-3 wraps of PTFE tape on male threads before assembly.
Tighten to 1.2-1.5N·m torque using crowfoot wrench. Avoid overtightening
which may deform O-ring seating surface. Compatible with ø4-6mm tubing.
| Property | Property Value |
|---|---|
| sku | X-APDT401 |
