Airtac X-APDT Adapter - Full Brass Threaded Side Tee X-APDT803
AirTAC X-APDT803 Full Copper Threaded Side Tee Fitting Specifications
- Model: X-APDT803
- Type: T-shaped tee with lateral threaded port
- Material: Full copper (C3604 lead-free brass)
- Port connections: 3 × PT1/8 (BSPP) female threads
- Thread standard: ISO 228 (G-series parallel threads)
- Pressure rating: 0.05-1.5 MPa (7-217 PSI)
- Temperature range: -5℃ to 120℃
- Surface treatment: Electro-polished nickel plating (3-5μm)
- Seal compatibility: Compatible with air, water, and non-corrosive gases
- Weight: 82g ±2g
- Dimensions: 24mm (L) × 24mm (W) × 28mm (H)
- Torque limit: 12-15 N·m max during installation
- Flow coefficient (Cv): 0.35
- Certification: RoHS compliant
Precision-machined brass tee connector featuring corrosion-resistant nickel plating and triple-port configuration. Designed for branching pneumatic/hydraulic lines in confined spaces with 360° rotatable lateral port for flexible orientation. Includes built-in O-ring grooves for optional sealing (O-rings not included).
- Modular pneumatic circuit distribution in automation cells
- Coolant line branching for CNC machine tools
- Compressed air manifolds in packaging machinery
- Instrumentation gas sampling systems
- Mobile equipment hydraulic control units
Installation protocol:
Apply thread sealant (liquid type recommended) to male threads only.
Avoid overtightening - use torque wrench for precise installation.
Rotate lateral port before final tightening to align flow direction.
Pressure test at 1.25× max operating pressure after assembly.
