Airtac X-APE Connector - T Tee X-APE8
AirTAC X-APE T-Type Tee Fitting X-APE8 Technical Details
- Model: X-APE8
- Type: T-shaped pneumatic tee connector (equal bore)
- Thread standard: Metric (M5×0.8) / Optional NPT1/8
- Material: Brass (CuZn39Pb3) with electroless nickel plating
- Pressure range: 0-1.0 MPa (145 psi)
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Weight: 8.2±0.3g
- Dimensions: 18mm(L) × 18mm(W) × 15mm(H)
- Surface hardness: ≥HV200
- Leakage rate: ≤3×10⁻² Pa·m³/s (helium test)
- Torque resistance: 1.5~2.0 N·m installation torque
Precision-machined tee connector featuring triple O-ring groove design (NBR seals included) for 360° leak-proof connections. The internal right-angle flow path maintains 85%+ original pressure efficiency with chamfered edges to reduce turbulence. Compatible with PU/Nylon tubing (ID 4mm).
- Branch line creation in compact pneumatic manifolds
- Modular assembly in pick-and-place robot EOAT
- Sensor air supply distribution networks
- Medical device pneumatic circuit splitting
- 3D printer air-driven cooling systems
Installation protocol:
Apply 2-3 drops of pneumatic lubricant (ISO VG32) on threads before assembly.
Use torque wrench for even pressure distribution - over-tightening may deform sealing grooves.
Recommended re-torque check interval: 5,000 operating cycles.
| Property | Property Value |
|---|---|
| sku | X-APE8 |
