Airtac X-APEG Adapter - T-Type Reducing Tee X-APEG106
AirTAC X-APEG106 T-Type Reducing Tee Fitting Detailed Specifications
- Model: X-APEG106
- Type: T-shaped reducing tee with metric threads
- Material: Lead-free brass with nickel plating (RoHS compliant)
- Main port size: PT1/8 (BSPP) female threads
- Branch port size: PT1/4 (BSPP) female threads
- Pressure rating: 0.05-1.5 MPa (7-217 psi)
- Temperature range: -5℃ to 80℃ (23℉ to 176℉)
- Weight: 28g ±2g (0.062 lbs)
- Dimensions:
- Length (main axis): 22mm
- Width (branch axis): 18mm
- Height: 26mm
- Surface roughness: Ra ≤1.6μm
- Seal type: Integral O-ring (NBR material)
- Vibration resistance: ≤10Hz at 2mm amplitude
- Corrosion resistance: 96hrs neutral salt spray test passed
Precision-engineered flow distribution component with stepped bore design (3.2mm at reduced port), featuring triple-layer electroless nickel plating for enhanced chemical resistance. The asymmetric T-configuration enables space-efficient plumbing in multi-circuit pneumatic systems while maintaining laminar flow characteristics. Includes pre-installed ethylene-propylene sealing washers compatible with most pneumatic fluids.
- Branch line creation in compact automation cells
- Pressure gauge multiplexing setups
- Modular pneumatic teaching systems
- Medical gas line distribution networks
- Robotic end-effector air supply splitting
Installation protocol:
Apply 1.2-1.8N·m torque during assembly. Use thread sealant only on male ports,
avoiding contamination of the internal flow channel. Perform pressure test
at 1.8MPa before initial operation.
| Property | Property Value |
|---|---|
| sku | X-APEG106 |
