Airtac X-APEG Adapter - T-Type Reducing Tee X-APEG1208
$4.15
Regular price
$11.65
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
X-APEG1208
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC X-APEG T-Type Reducing Tee Fitting X-APEG1208 Specifications
- Model: X-APEG1208
- Type: T-Type Reducing Tee (Male Threads)
- Material: Lead-free brass (CuZn39Pb0.5)
- Surface Treatment: Electroless nickel plating (5-8μm)
- Pressure Rating: 1.5 MPa (217 psi)
- Temperature Range: -5℃ to 120℃
- Thread Standards: ISO 228 G1/8" (Port A) × G1/4" (Port B & C)
- Hex Size: 17mm wrench flat
- Flow Coefficient (Cv): 0.18
- Weight: 48g ±2g
- Dimensions: 35mm (L) × 24mm (W) × 30mm (H)
- Seal Type: Metal-to-metal sealing (NBR O-ring optional)
- Vibration Resistance: ≤15Hz @ 2mm amplitude
- Certifications: RoHS compliant, REACH SVHC-free
Precision-engineered reducing tee for pneumatic systems requiring flow division with pressure drop compensation. Features corrosion-resistant nickel plating and zero leakage design through CNC-machined orthogonal fluid paths. Compatible with air, inert gases, and vacuum applications.
Typical Applications:
- Multi-axis pneumatic tooling manifolds
- Vacuum circuit distribution in packaging machinery
- Compressed air branching in CNC equipment
- Laboratory gas mixing stations
- Robotic end-effector pneumatic networks
Installation guidelines:
Apply 30-40Nm torque during assembly. Use thread sealant only on male ports.
Align flow arrow (cast on body) with primary supply direction. Avoid cross-threading
by hand-tightening 3 full turns before final wrench tightening.
Fluid Compatibility:
- Optimal performance with ISO 8573-1 Class 3 air quality
- Not recommended for steam or aggressive chemicals
- Annual inspection recommended for industrial environments
| Property | Property Value |
|---|---|
| sku | X-APEG1208 |
