Airtac X-APEG Adapter - T-Type Reducing Tee X-APEG1210
AirTAC X-APEG1210 T-Type Reducing Tee Fitting Specifications
- Model: X-APEG1210
- Type: T-Type Reducing Tee (Equal Branch)
- Material: Lead-free brass with nickel plating (RoHS compliant)
- Thread Standards: Rc1/8 (Port A) × Rc1/8 (Port B) × Rc1/10 (Port C)
- Operating Pressure: 0.05-1.0 MPa
- Burst Pressure: ≥3.0 MPa
- Temperature Range: -20℃ to 80℃
- Surface Roughness: Ra ≤1.6μm (internal flow path)
- Weight: 12.5g ±0.3g
- Dimensions: 30mm(L) × 25mm(W) × 18mm(H)
- Seal Type: Metal-to-metal sealing (no additional O-ring required)
- Vibration Resistance: 10-55Hz, 1.5mm amplitude
- Corrosion Resistance: Passes 96hr neutral salt spray test
Precision-engineered reducing tee featuring tapered pipe threads and optimized flow path geometry. The asymmetrical design minimizes turbulent flow at branch connections while maintaining 25% lower pressure drop compared to standard tees. Electrostatic-resistant packaging included for cleanroom applications.
- Pneumatic circuit branching with differential pressure requirements
- Instrumentation air distribution in semiconductor fab systems
- Coolant line reducers in CNC machine tool manifolds
- Vacuum system junctions with multiple pump capacities
- Medical gas line adapters for mixed diameter circuits
Installation note:
Apply 2-3 wraps of PTFE tape on male threads using clockwise winding.
Tighten 1.5-2 turns past finger-tight position. Avoid overtightening -
maximum torque 1.2N·m. Orient flow arrow (cast on body) toward primary supply line.
| Property | Property Value |
|---|---|
| sku | X-APEG1210 |
