Airtac X-APHW Connector - Female Thread Swivel Tee X-APHW1002
AirTAC X-APHW F-Type Threaded Rotary Tee Fitting X-APHW1002 Technical Details
- Model: X-APHW1002
- Type: 3-way rotary union (F-type threaded)
- Thread standard: Metric fine thread (M5×0.8)
- Material: Anodized aluminum alloy body + PPS resin rotor
- Max working pressure: 1.0 MPa
- Temperature range: -5℃ to 80℃
- Seal material: Fluororubber (FKM)
- Rotational torque: ≤0.15 N·m @ 0.5 MPa
- Leakage rate: ≤5 bubbles/min (ISO 6952)
- Certifications: RoHS compliant
- Weight: 55±2g
- Dimensions: 30mm(L) × 20mm(W) × 20mm(H)
High-precision rotary joint featuring 360° continuous rotation capability with triple sealing structure for leak-free performance. The hardened stainless steel ball bearing ensures smooth rotation under pressure. Optimized flow path design reduces air turbulence (pressure drop ≤0.02 MPa @ 0.5 MPa).
- Rotating workholding fixtures in CNC automation
- Multi-axis pneumatic tool changers
- Packaging line rotary air supply systems
- Medical device rotary pneumatic connections
- Semiconductor wafer handling robots
Installation guidelines:
Apply 2-3 wraps of PTFE tape on male threads. Tighten to 1.2-1.5 N·m torque.
Perform rotational alignment before final tightening. Lubricate rotating parts
with silicone grease (Parker O-Lube 111 recommended) during maintenance.
| Property | Property Value |
|---|---|
| sku | X-APHW1002 |
