AirTAC X-APHW F-Type Threaded Rotary Tee X-APHW1003 Specifications
- Model: X-APHW1003
- Type: F-Type Threaded Rotary Tee (3-way)
- Thread Standard: G1/8 (BSPP) female threads
- Material: Nickel-plated brass body
- Max Working Pressure: 1.0 MPa (145 psi)
- Temperature Range: -5℃ to 80℃ (23℉ to 176℉)
- Weight: 28g ±1g
- Dimensions: 50mm(L) × 16mm(W) × 16mm(H)
- Seal Material: NBR/FKM optional
- Flow Coefficient: Cv 0.15
- Rotation Angle: 360° continuous rotation
- Port Alignment: Precision machined with ±0.5mm tolerance
- Surface Treatment: Electroless nickel plating (8-12μm)
High-density rotary tee featuring tool-free manual rotation for flexible piping layouts. The through-hole design minimizes pressure drop, while the double O-ring seal ensures leak-free performance even under vibration. Compatible with ISO 1179-2 standards.
Typical Applications:
- Modular pneumatic circuit branching in automation cells
- Tool changer interfaces on CNC machines
- Compressed air distribution in packaging lines
- Medical gas line manifold systems
- Robotic end-effector pneumatic networks
Installation note:
Apply 2-3 wraps of PTFE tape on male threads before assembly.
Tighten with 8-10 N·m torque using a crowfoot wrench to avoid
deformation. Rotate joint body before final system pressurization.
