Airtac X-APHW Connector - Female Thread Swivel Tee X-APHW1004
AirTAC X-APHW F-Type Threaded Rotary Tee X-APHW1004 Full Specifications
- Model: X-APHW1004
- Type: T-shaped three-way rotary joint with F-type threads
- Thread standard: G1/8 (ISO228-1 compliant)
- Material: Nickel-plated brass body
- Seal material: NBR/FKM dual-material O-rings
- Pressure range: 0.05-1.0 MPa
- Temperature range: -20℃ to 80℃
- Rotation angle: 360° continuous rotation
- Leakage rate: ≤3 bubbles/min (ISO6952-1 test standard)
- Weight: 18.5g ±0.5g
- Dimensions: 24mm(W) × 24mm(D) × 31.5mm(H)
- Surface treatment: Electroless nickel plating (5-8μm)
- Torque resistance: ≤1.2N·m at 0.6MPa
- Certifications: RoHS, REACH, ISO9001
Precision-engineered rotary tee featuring dual-seal technology for leak-free pneumatic connections. The self-aligning design compensates for up to 3° angular misalignment during installation. Nickel plating provides corrosion resistance in humid environments. Compatible with ISO 8434-1 dash size -4 (6mm) tubing systems.
- Multi-axis pneumatic tool changers
- Rotating workholding fixtures in CNC machines
- Automated packaging line diverters
- Semiconductor wafer handling robots
- Beverage filling station rotary unions
Installation protocol:
Apply 1.5-2 wraps of PTFE tape on male threads (ASME B1.20.1 specification).
Tighten with 12-15N·m torque using 17mm crowfoot wrench.
Perform pressure test at 1.25× operating pressure after installation.
| Property | Property Value |
|---|---|
| sku | X-APHW1004 |
