Airtac X-APHW Connector - Female Thread Swivel Tee X-APHW602
$6.73
Regular price
$14.23
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
X-APHW602
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC X-APHW602 F-Type Threaded Rotary Tee Specifications
- Model: X-APHW602
- Type: F-type thread rotatable tee (3-way)
- Thread standard: Metric fine thread (M5×0.8)
- Material: Nickel-plated brass (C3604 lead-free)
- Pressure range: 0.05–1.0 MPa
- Temperature range: -5℃ to 80℃
- Port configuration: 1 inlet (P), 2 outlets (A/B)
- Rotation angle: 360° continuous rotation
- Seal type: HNBR O-rings (high-pressure resistant)
- Surface roughness: Ra ≤1.6μm
- Weight: 28±2g
- Dimensions: 32mm(L) × 24mm(W) × 24mm(H)
- Certification: RoHS compliant
Precision-engineered rotary tee featuring maintenance-free rotation mechanism with double-bearing design. The anti-vibration thread locking system prevents unintended rotation during operation. Compatible with ISO 15407-1 pneumatic standards.
Typical Applications:
- Modular pneumatic circuit branching in robotic arms
- Compact air distribution in semiconductor handling systems
- Multi-axis tool changers requiring rotational flexibility
- High-cycle automation lines with space constraints
- Medical gas control panel manifold connections
Installation guidelines:
Apply thread sealant (PTFE tape recommended) on male threads only.
Tighten to 1.2-1.5 N·m torque using 7mm open-end wrench.
Perform pressure test at 1.5× working pressure after installation.
| Property | Property Value |
|---|---|
| sku | X-APHW602 |
