Airtac X-APHW Connector - Female Thread Swivel Tee X-APHW603
AirTAC X-APHW603 Threaded Rotary Tee (F-Type) Specifications
- Model: X-APHW603
- Type: F-Type Threaded 360° Rotatable Tee
- Thread Standard: Metric (M5×0.8)
- Material: Brass body with chrome plating
- Seal Material: NBR (Nitrile Rubber)
- Max Operating Pressure: 1.0 MPa
- Proof Pressure: 1.5 MPa
- Temperature Range: -5℃ to 80℃ (no ice formation)
- Installation Torque: 0.4-0.6 N·m (recommended)
- Rotation Angle: 360° continuous rotation
- Port Configuration: 1 inlet (vertical), 2 outlets (horizontal)
- Weight: 18g ±0.5g
- Dimensions: 20mm (L) × 19mm (W) × 24mm (H)
- Surface Hardness: HV300-400
- Flow Coefficient: Cv≈0.12
Precision-machined tee connector featuring tool-free directional adjustment, designed for modular pneumatic systems. The rotating mechanism maintains seal integrity through 5,000+ rotation cycles. Gold-plated brass construction prevents galvanic corrosion when used with aluminum manifolds.
- Multi-axis robotic arm pneumatic distribution
- Compact PLC-controlled automation stations
- Laboratory instrument gas line splitting
- Packaging machine air circuit branching
- Medical device pneumatic systems requiring sterile connections
Installation Guidelines:1. Hand-tighten initially, then apply final torque using calibrated wrench
2. Align outlet ports before system pressurization
3. Apply thread sealant only on male threads (not required for tapered threads)
4. Maximum angular vibration tolerance: ±2° at 50Hz
