Airtac X-APK Connector-5-Way X-APK6
AirTAC X-APK6 5-Way Connector Technical Details
- Model: X-APK6
- Type: 5-way pneumatic connector (ISO standard)
- Body material: Brass with nickel plating
- Port size: G1/8 (BSPP thread)
- Operating pressure: 0.05-1.0 MPa
- Temperature range: -20℃ to 80℃
- Seal material: NBR (Nitrile rubber)
- Flow capacity: 1,200 L/min (ANR)
- Tube compatibility: Ø6mm (1/4") pneumatics tubing
- Thread engagement: ≥2 full rotations required
- Weight: 180g ±5g
- Dimensions: 50mm(L) × 50mm(W) × 30mm(H)
- Vibration resistance: ≤10Hz @ 2.5mm amplitude
- Protection rating: IP40 (non-weatherproof)
High-flow 5-port manifold base designed for modular pneumatic system integration. Features cross-shaped flow channels with precision-machined internal passages (0.8mm surface roughness) for minimal pressure drop. The 360° rotatable ports allow flexible piping arrangements in confined spaces. Includes integrated mounting slots for DIN rail or direct panel installation.
- Centralized air distribution in automation cells
- Modular valve terminal assemblies
- Pneumatic control cabinets
- Multi-axis actuator synchronization systems
- Educational pneumatic training rigs
Installation guidelines:
Apply 2-3 wraps of PTFE tape on male threads (do not over-tighten - max torque 1.5N·m).
For vertical installations, orient exhaust ports downward to prevent debris accumulation.
Always perform leak test at 0.6MPa for 10 minutes post-installation.
