Airtac X-APKB Connector - Threaded 5 Port X-APKB1002
AirTAC X-APKB Threaded 5-Way Fitting X-APKB1002 Technical Details
- Model: X-APKB1002
- Type: Pneumatic manifold with 5-way threaded ports
- Thread Standard: M5×0.8 (metric fine thread)
- Material: Anodized aluminum alloy 6063-T5
- Surface Hardness: HV 0.3/15 ≥12°
- Operating Pressure: 0.05-1.0 MPa
- Temperature Range: -20℃ to 80℃
- Port Configuration: 1 inlet (P), 2 outlets (A/B), 2 exhausts (EA/EB)
- Seal Material: NBR (Nitrile) O-rings
- Installation Torque: 1.2-1.5 N·m (recommended)
- Weight: 28g ±0.5g
- Dimensions: 34mm(L) × 24mm(W) × 18mm(H)
- Surface Treatment: Clear anodized (8-12μm thickness)
- Pressure Drop: ≤0.02 MPa @ 0.5 MPa supply
- Leakage Rate: <3 cm³/min @ 0.6 MPa
Precision-machined flow distribution block designed for compact pneumatic circuit integration. Features corrosion-resistant anodized finish and multi-directional port alignment options. The asymmetric port numbering (P-A-B-EA-EB) allows flexible piping layouts in confined spaces. Includes integrated mounting slots for M3 fasteners.
- Miniature pneumatic valve manifold assemblies
- Robotic end-effector control systems
- Laboratory automation air distribution nodes
- Packaging machine actuator clusters
- Medical device pneumatic control units
Installation note:
Apply thread sealant (Loctite 5452 recommended) on male threads only.
Maximum angular misalignment tolerance: ±3°. Avoid overtightening -
use calibrated torque wrench for repeated installations.
- AirTAC SMCV series compact valves
- 4mm OD polyurethane tubing (PU-4×2.5)
- M5 to G1/8 adapters (X-ATK05 series)
- Pneumatic quick connectors (QCHD-4-M5)
| Property | Property Value |
|---|---|
| sku | X-APKB1002 |
