Airtac X-APKB Connector - Threaded 5 Port X-APKB401
AirTAC X-APKB401 Threaded 5-Way Manifold Specifications
- Model: X-APKB401
- Type: 5-way threaded manifold (P-A-B-R1-R2 configuration)
- Thread standard: G (BSPP) / NPT optional
- Port sizes: G1/8, G1/4, G3/8, G1/2 (customizable)
- Material: Nickel-plated brass body
- Seal material: NBR/FKM (optional high-temp seals)
- Operating pressure: 0.05-1.5 MPa
- Temperature range: -5℃ to 80℃ (extended to 120℃ with FKM seals)
- Flow rate: 450 NL/min @ 0.5 MPa
- Weight: 82g ±2g
- Dimensions: 32mm(W) × 32mm(D) × 40mm(H)
- Surface roughness: Ra ≤3.2μm
- Torque resistance: ≤29.4N·m
- Certification: RoHS compliant
High-density flow distribution block with precision-machined internal channels, designed for multi-circuit pneumatic systems requiring compact manifold solutions. Features leak-proof design with dual O-ring seals and anti-vibration thread locking. Compatible with ISO 15407-1 standard valves.
- Multi-axis pneumatic actuator control systems
- Modular assembly line clamping units
- Plastic injection molding machine air distribution
- Automated packaging machine valve clusters
- Semiconductor handling equipment manifolds
Installation protocol:
Apply 1.5-2 wraps of PTFE tape on male threads (clockwise winding).
Tighten with 12-15N·m torque using flank-contact wrench.
Avoid side-load stress during plumbing.
| Property | Property Value |
|---|---|
| sku | X-APKB401 |
