Airtac X-APKB Connector - Threaded 5 Port X-APKB804
AirTAC X-APKB804 Threaded Five-Way Union Connector Specifications
- Model: X-APKB804
- Type: Threaded five-way union (ISO standard)
- Material: Brass with nickel plating (stainless steel optional)
- Thread standard: G1/8 (NPT1/8 available on request)
- Port configuration: 5 ports (1 inlet, 4 outlets)
- Operating pressure: 0-1.0 MPa (145 psi)
- Proof pressure: 1.5 MPa
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Surface hardness: ≥HV200
- Leakage rate: ≤3×10⁻³ Pa·m³/s (helium test)
- Weight: 118g ±2g
- Dimensions: 60mm(L) × 34mm(W) × 34mm(H)
- Protection rating: IP40 (dust protected)
- Vibration resistance: 10-55Hz, 1.5mm amplitude
High-density fluid distribution block with precision-machined internal channels, designed for multi-branch pneumatic circuit connections. Features anti-corrosion coating and chamfered ports for smooth tubing insertion. The cross-drilled flow paths minimize pressure drop (ΔP < 0.02MPa @ 0.5MPa input). Compatible with PU, nylon, and rubber tubing (4-6mm OD).
- Multi-actuator control systems in assembly lines
- Plastic injection molding machine air distribution
- Automated packaging equipment manifold systems
- Industrial robot end-effector pneumatic networks
- Food processing equipment air supply junctions
Installation note:
Apply thread sealant tape (PTFE) on male threads using clockwise wrapping.
Tightening torque should not exceed 2.5N·m. Perform pressure test at 1.2×
working pressure before initial use. Regular leakage checks recommended
every 500 operational hours.
| Property | Property Value |
|---|---|
| sku | X-APKB804 |
