Airtac X-APKG Adapter - Reducing 5-Way Fitting X-APKG64
AirTAC X-APKG64 Reducing Five-way Connector Specifications
- Model: X-APKG64
- Type: Threaded reducing manifold with 5 ports
- Material: Brass with Nickel Plating (surface hardness ≥HV200)
- Port Configuration: 1 inlet (PT1/2) + 4 outlets (PT3/8)
- Pressure Range: 0.05-1.0 MPa
- Temperature Range: -20℃ to 80℃
- Thread Standard: JIS B0203 (Parallel)
- Seal Material: NBR (Nitrile Rubber)
- Proof Pressure: 1.5 MPa
- Burst Pressure: 3.0 MPa
- Weight: 215g ±5g
- Dimensions: 78mm(L) × 54mm(W) × 54mm(H)
- Surface Roughness: Ra ≤3.2μm (sealing surfaces)
- Vibration Resistance: 10-60Hz, 1.5mm amplitude
High-density flow distribution block with precision-machined pressure chambers, designed for multi-branch pneumatic circuits requiring stepped-down pressure. Features anti-vibration thread locks and corrosion-resistant plating. Compatible with air, inert gases, and light hydraulic fluids (ISO VG32 or lower).
- Multi-axis pneumatic actuator synchronization systems
- CNC machine tool clamping circuits
- Automated assembly line distribution manifolds
- Packaging machine air flow regulation stations
- Semiconductor manufacturing gas distribution
Installation note:
Apply 2-3 wraps of PTFE tape on male threads using clockwise winding direction.
Tighten to 14-18 N·m torque with staggered sequence (pattern: center-outward).
Avoid overtightening - maximum allowable thread deformation: 0.15mm.
| Property | Property Value |
|---|---|
| sku | X-APKG64 |
