Airtac X-APKJ Push-In 5-Way Fitting X-APKJ10
AirTAC X-APKJ10 Insertion-Type 5-Port Manifold Specifications
- Model: X-APKJ10
- Type: Push-in fitting 5-way manifold (3-position center closed)
- Port configuration: P (pressure), A/B (actuator ports), R/S (exhaust)
- Thread standards: PT1/8 (BSPP) & M5x0.8 optional
- Operating pressure: 0.05–1.0 MPa
- Max flow rate: 300 L/min (ANR)
- Temperature range: -20℃ to 80℃
- Body material: Anodized aluminum alloy (A6063)
- Seal material: Nitrile rubber (NBR) with fiber reinforcement
- Weight: 28g ±1g
- Dimensions: 32mm(L) × 26mm(W) × 34mm(H)
- Port-to-port spacing: 10mm (vertical), 8mm (horizontal)
- Leakage: <0.1 mL/min under 0.5 MPa
- Vibration resistance: 10–55Hz with 1.5mm amplitude
Modular pneumatic manifold designed for rapid assembly in multi-valve systems. Features color-coded ports (P-red, A/B-blue/green, R/S-black) and tool-free tubing insertion with 2.5–4mm OD tube compatibility. Anti-vibration structure prevents accidental disconnection in mobile applications.
- Multi-station pneumatic control clusters
- Robotic end-effector tool changers
- Compact valve islands in packaging lines
- Laboratory pneumatic sequencing systems
- CNC machine tool clamping circuits
Installation protocol:
Ensure tubing is cut square and inserted fully until the white indicator ring becomes visible.
For M5 threaded connections, apply 0.8–1.2Nm torque using a crowfoot wrench to prevent port deformation.
| Property | Property Value |
|---|---|
| sku | X-APKJ10 |
