Airtac X-APKJ Push-In 5-Way Fitting X-APKJ1006
$4.36
Regular price
$11.86
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
X-APKJ1006
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC X-APKJ1006 Insertion-Type 5-Way Fitting Technical Details
- Model: X-APKJ1006
- Type: Insertion-type 5-way manifold (ISO 15407-1 compliant)
- Port thread: PT1/4 (BSPP) with G1/4 optional
- Max working pressure: 1.0 MPa
- Pressure range: 0.1–1.0 MPa
- Material: Nickel-plated brass body
- Seal type: NBR O-rings (Fluorocarbon optional)
- Temperature range: -5℃ to 80℃ (with NBR seals)
- Surface treatment: Electroless nickel plating (8-12μm)
- Leakage rate: ≤3 bubbles/min (ISO 6952 test standard)
- Weight: 52g ±2g
- Dimensions: 50mm(L) × 32mm(W) × 38mm(H)
- Port spacing: 20mm center-to-center (ISO modular)
High-density pneumatic distribution block with tool-free insertion design, featuring integrated flow channels for multi-actuator control systems. Anti-vibration structure maintains connection integrity in high-cycle applications. Pre-lubricated seals enable 500,000+ cycle durability.
Primary Applications:
- Modular pneumatic control panels
- Multi-axis robotic end effector manifolds
- PLC-controlled assembly line stations
- Textile machinery air distribution
- Semiconductor handling equipment
Installation protocol:
Use torque-limited driver (1.2-1.5N·m) for tube insertion.
Apply thread sealant only on male ports, not manifold base.
Requires ISO 8434-1 compliant tubing for leak-free operation.
| Property | Property Value |
|---|---|
| sku | X-APKJ1006 |
