Airtac X-APKJ Push-In 5-Way Fitting X-APKJ1008
AirTAC X-APKJ1008 Insertion-Type 5-Way Junction Fitting
- Model: X-APKJ1008
- Type: Insertion-style 5-port pneumatic connector
- Material: Reinforced POM (Polyoxymethylene) body
- Tube compatibility: Ø8mm (5/32") OD pneumatic tubing
- Operating pressure: 0.5-1.0 MPa (72.5-145 PSI)
- Temperature range: -20℃ to 60℃ (-4°F to 140°F)
- Installation type: Push-in locking mechanism
- Seal material: Nitrile rubber (NBR) O-rings
- Thread standards: M5 auxiliary ports
- Weight: 28g ±1g
- Dimensions: 30mm(L) × 25mm(W) × 20mm(H)
- Vibration resistance: ≤50m/s² (ISO 10816-3)
- IP rating: IP40 (non-immersive environments)
High-density flow distribution fitting designed for multi-directional pneumatic circuit branching. Features color-coded port indicators (blue for exhaust, red for pressure) and tool-free tube insertion. The chamfered edges prevent tubing abrasion during installation. Compatible with ISO 1635 and JIS B8381 standards.
- Multi-cylinder synchronization systems
- Compact robotic arm pneumatic networks
- Assembly line clamping circuits
- Modular pneumatic teaching setups
- Air amplifier distribution nodes
Installation protocol:
Cut tubing ends square (90°±2°) before insertion. Engage locking collar with
1/4 turn until audible click. Maximum permissible lateral force: 15N.
Recommended torque for M5 ports: 0.8-1.2N·m.
- Effective flow area: 7.2mm²
- Pressure drop: ≤0.02MPa at 500NL/min
- Leakage rate: <5cm³/min at 0.6MPa
| Property | Property Value |
|---|---|
| sku | X-APKJ1008 |
