Airtac X-APKJ Push-In 5-Way Fitting X-APKJ8
AirTAC X-APKJ8 Insertion-Type 5-Way Fitting Technical Details
- Model: X-APKJ8
- Type: Compression fitting with built-in check valve
- Port configuration: 5-way manifold (1 input, 4 outputs)
- Thread standard: G1/8 (ISO228 compliant)
- Material: Nickel-plated brass body
- Seal material: HNBR (Hydrogenated Nitrile)
- Operating pressure: 0.2-1.0 MPa
- Proof pressure: 1.5 MPa
- Temperature range: -5℃ to 80℃
- Tube compatibility: Φ4mm & Φ6mm pneumatic tubing
- Flow coefficient (Cv): 0.45
- Weight: 98g ±2g
- Dimensions: 60mm(L) × 25mm(W) × 25mm(H)
- Vibration resistance: ≤10Hz @ 1.5mm amplitude
- Certifications: RoHS compliant
High-density distribution manifold with integrated flow control, featuring a one-way valve design that prevents reverse airflow. The compact hexagonal body allows tool-free tube insertion through its collet-style retention mechanism. Nickel plating provides corrosion resistance in humid environments (salt spray test passed: 48hrs).
- Multi-actuator pneumatic circuits in assembly lines
- Modular pneumatic teaching equipment
- Medical gas distribution systems
- Robotic end-effector air supply branching
- Packaging machine air nozzle arrays
Installation protocol:
Tighten with 1.2-1.5N·m torque using 17mm wrench. Insert tubes perpendicularly until
audible "click". Perform leak test at 0.6MPa for 3 minutes. Maximum 90° rotation
allowed post-installation for hose routing.
| Property | Property Value |
|---|---|
| sku | X-APKJ8 |
