Airtac X-APKJ Push-In 5-Way Fitting X-APKJ804
AirTAC X-APKJ804 Insertion-Type 5-Way Fitting Technical Details
- Model: X-APKJ804
- Type: 5-port manifold base (insertion type)
- Material: Aluminum alloy (anodized surface treatment)
- Port thread size: M5 × 0.8 (ISO standard)
- Operating pressure range: 0.05–1.0 MPa
- Proof pressure: 1.5 MPa
- Temperature range: -20℃ to 80℃
- Seal material: NBR (Nitrile rubber)
- Port configuration: 1 inlet (P), 2 outlets (A/B), 2 exhausts (R/S)
- Mounting style: ISO 15407-1 compliant sub-base installation
- Weight: 228±5g
- Dimensions: 54mm(L) × 44mm(W) × 26mm(H)
- Surface hardness: HV 80-100 (anodized layer)
- Vibration resistance: ≤49 m/s² (10-150Hz)
High-density pneumatic manifold designed for multi-valve stacking in compact automation systems. Features precision-machined air passages with anti-leakage design and oxidation-resistant coating. The staggered port arrangement enables efficient piping layout in confined spaces. Compatible with ISO 15407-1 standard solenoid valves.
- Multi-valve clusters in robotic end effectors
- Modular pneumatic control panels
- Textile machinery air distribution systems
- Semiconductor handling equipment
- Assembly line fixture controls
Installation note:
Use torque-controlled tools (recommended 1.2-1.5N·m) for valve mounting.
Apply silicone-free lubricant on seals during assembly. Maintain minimum
15mm clearance between stacked units for heat dissipation.
- X-APKJ series valves (direct mounting)
- ISO 15407-1 Type 1 valves via adapter plates
- Maximum stack height: 8 units (with reinforcement brackets)
| Property | Property Value |
|---|---|
| sku | X-APKJ804 |
