Description
AirTAC X-APKJ806 Insertion-Type 5-Way Junction Fitting
- Model: X-APKJ806
- Type: Pneumatic manifold with 5 ports (P, A, B, R1, R2)
- Thread standard: Metric (M5 × 0.8) / Optional BSPP
- Port configuration: 1 input (P), 2 outputs (A/B), 2 exhausts (R1/R2)
- Operating pressure: 0.1–1.0 MPa
- Max flow rate: 350 L/min (ANR)
- Temperature range: -5℃ to 80℃
- Material: Brass (nickel-plated) / Optional stainless steel
- Seal material: NBR (standard) / FKM (optional)
- Weight: 82g ±2% (brass version)
- Dimensions: 40mm(L) × 30mm(W) × 30mm(H)
- Surface roughness: Ra ≤3.2μm
- Vibration resistance: 10–55Hz (1.5mm amplitude)
Compact multi-port junction block designed for modular pneumatic system integration. Features self-aligning O-ring seals and tool-free insertion mounting. Optimized for directional control valve clusters with integrated exhaust mufflers. Rated for 1 million cycles at full pressure.
Typical Applications:
- Multi-cylinder sequencing in assembly lines
- Centralized exhaust management for valve terminals
- Space-constrained pneumatic control panels
- Robotic end-effector air distribution
- Medical device pneumatic logic systems
Installation protocol:
Apply silicone-free lubricant to O-rings before insertion.
Torque mounting screws to 0.5–0.6 N·m in crisscross pattern.
Use ISO 8573-1 Class 3 compressed air to prevent seal degradation.
