Airtac X-APV Elbow 2-Way Fitting X-APV14
AirTAC X-APV14 L-Type Two-Way Connector Technical Details
- Model: X-APV14-L
- Type: L-shaped push-in pneumatic connector (straight thread)
- Material: Nickel-plated brass body
- Seal material: NBR/PU compound
- Thread standard: G1/4 (BSPP) female thread
- Tube compatibility: Ø4mm (1/8") OD pneumatic tubing
- Max working pressure: 1.0 MPa (145 psi)
- Temperature range: -20℃ to 80℃
- Proof pressure: 3.0 MPa
- Leakage rate: ≤0.1 mL/min @ 0.5 MPa
- Weight: 28g ±1g
- Dimensions: 32mm(L) × 16mm(W) × 22mm(H)
- Surface treatment: Electroless nickel plating (5-8μm)
- Vibration resistance: 10-55Hz, 1.5mm amplitude
- Certification: RoHS compliant
Precision-engineered L-shaped pneumatic connector with 90° flow path optimization, featuring tool-free tube insertion and positive-lock mechanism. The corrosion-resistant nickel plating ensures durability in humid environments, while the dual-material seal prevents air leakage under high-cycle operations.
- Pneumatic circuit branching in robotic arm assemblies
- Space-constrained manifold connections
- Air tool quick-connect systems
- Packaging machine air distribution networks
- Medical device pneumatic control units
Installation protocol:
Apply 2-3 wraps of PTFE tape on male threads (do not over-tighten beyond 15N·m).
Ensure tube ends are cut square and deburred before insertion. Rotate the blue collar
45° clockwise for secure locking. Perform pressure test at 1.5× operating PSI after installation.
| Property | Property Value |
|---|---|
| sku | X-APV14 |
