Airtac X-APX Adapter - Y-Type Threaded Tee X-APX604
AirTAC X-APX604 Y-Type Threaded Tee Fitting Technical Details
- Model: X-APX604
- Type: Y-type 3-way tee with unified metric thread
- Thread Standard: M5×0.8 (Male-Female-Female configuration)
- Material: Nickel-plated brass (C3604)
- Seal Type: Integrated NBR O-ring (replaceable)
- Pressure Rating: 0.2-1.0 MPa (29-145 PSI)
- Temperature Range: -20℃ to 80℃ (continuous operation)
- Flow Coefficient: Cv≈0.15
- Surface Treatment: Electroless nickel plating (8-12μm thickness)
- Weight: 32±2g
- Dimensions: 30mm(L) × 20mm(W) × 20mm(H)
- Compliance: RoHS 2.0 compliant
- Thread Engagement Depth: 5mm minimum
Precision-machined flow distribution component with triple sealing surfaces, engineered for stable branching in low-to-medium pressure pneumatic systems. Features 120° angular port alignment for optimized flow dynamics and space-efficient plumbing layouts. The electroless nickel coating provides corrosion resistance in humid environments.
- Modular pneumatic manifold extensions
- PLC-controlled automation test benches
- Dual-actuator synchronization circuits
- Medical gas line distribution nodes
- Robotic end-effector air supply splits
Installation protocol:
Apply PTFE tape clockwise on male threads (2.5 wraps recommended).
Torque limit: 1.2-1.5 N·m. Avoid overtightening to prevent thread
deformation. For vertical installations, position branch port upward
to prevent condensate accumulation.
| Property | Property Value |
|---|---|
| sku | X-APX604 |
