Airtac X-APX Adapter - Y-Type Threaded Tee X-APX6M12
AirTAC X-APX Y-Type Threaded Tee Connector X-APX6M12 Technical Details
- Model: X-APX6M12
- Series: X-APX Compact Pneumatic Fittings
- Material: Nickel-plated brass (C3604 lead-free)
- Thread type: Metric fine thread (Y-type branch)
- Thread size: M12×1.0 (triple ports)
- Seal type: Integrated NBR O-ring (pre-lubricated)
- Pressure range: 0-1.0 MPa (145 psi)
- Temperature range: -20℃ to 80℃ (continuous duty)
- Surface hardness: HV 200±50 (nickel plating)
- Weight: 38±2g
- Dimensions: 32mm(L) × 24mm(W) × 24mm(H)
- Port angles: 120° between branch ports
- Flow coefficient (Cv): 0.15
- Vibration resistance: 10-55Hz, 1.5mm amplitude
- Certifications: RoHS compliant, ISO 6150-B standard
High-density Y-shaped flow divider engineered for compact pneumatic distribution systems. Features precision cold-forged construction with anti-vibration thread locking design. The chamfered port edges prevent tube abrasion during installation. Rated for 500,000+ duty cycles with ≤0.01MPa pressure drop at max flow.
- Modular pneumatic manifolds in packaging robots
- Triple actuator synchronization circuits
- CNC machine tool cooling air distribution
- Mobile hydraulic hybrid systems (air-oil separation)
- Laboratory pneumatic sample handling arrays
Installation protocol:
Apply 2-3 drops of PTFE sealant on male threads (not required for initial assembly).
Tightening torque: 12-15 N·m. Maximum angular misalignment tolerance: ±3°.
Always purge lines before first use to remove metal particulates.
| Property | Property Value |
|---|---|
| sku | X-APX6M12 |
