Airtac X-APX Adapter - Y-Type Threaded Tee X-APX6M16
AirTAC X-APX6M16 Y-Type Threaded Tee Fitting Technical Details
- Model: X-APX6M16 (X-APX Series)
- Type: Y-shaped triple port connector with metric threads
- Thread specification: M16×1.5 (ISO 6149 compliant)
- Material: Brass CW617N with nickel plating (3-5μm thickness)
- Pressure rating: 0.2-1.0 MPa (29-145 PSI)
- Temperature range: -20℃ to 80℃ (NBR seals)
- Surface hardness: ≥HV200
- Weight: 48g ±2g
- Dimensions: 50mm(L) × 30mm(W) × 30mm(H)
- Port configuration: 3-way equal diameter (16mm)
- Torque resistance: ≤25N·m installation torque
- Leakage rate: ≤3 bubbles/min under 0.5MPa pressure
Precision-machined flow distribution component featuring 120° branch angle for optimal pneumatic circuit efficiency. The electroless nickel coating provides enhanced corrosion resistance (96hr salt spray test passed). Internal smooth bore design minimizes pressure drop (ΔP <0.02MPa @ 500NL/min).
- Modular pneumatic manifolds in assembly robots
- Air supply distribution in CNC tool changers
- Compressed air branching for packaging line actuators
- Vacuum system plumbing in electronic component handling
- Instrumentation air networks in chemical process control
Installation guidelines:
Apply PTFE tape 1.5-2 turns clockwise on male threads.
Use two wrenches during assembly - counter-hold base fitting while tightening.
Maximum recommended retightening cycles: 3 times.
| Property | Property Value |
|---|---|
| sku | X-APX6M16 |
