Airtac X-APX Adapter - Y-Type Threaded Tee X-APX6M20
$4.77
Regular price
$12.27
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
X-APX6M20
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC X-APX6M20 Y-Type Threaded Tee Fitting Specifications
- Model: X-APX6M20
- Type: Y-type (120° branch) metric threaded tee
- Thread standard: ISO 6149 (Metric O-ring seal)
- Main thread size: M20×1.5
- Branch thread size: M20×1.5
- Material: Aluminum alloy 6063-T5 (anodized)
- Seal type: Integral NBR O-ring (replaceable)
- Pressure rating: 0.05-1.0 MPa (operating), 1.5 MPa burst
- Temperature range: -20℃ to 80℃ (with NBR seals)
- Surface finish: Matte black anodization (12-15μm)
- Weight: 82g ±3g
- Dimensions: 46mm (L) × 34mm (W) × 54mm (H)
- Port orientation: 120° angled branch flow path
- Flow coefficient (Cv): 0.25
- Vibration resistance: ≤10Hz/1.5mm amplitude
Precision-machined Y-shaped flow divider combining three M20 ports in compact 120° configuration. Features self-aligning thread design with built-in backup rings for vibration resistance. The anti-leak groove design maintains seal integrity during thermal expansion.
Typical Applications:
- Pneumatic manifold splitting in robotic arms
- Multi-axis CNC machine tool air networks
- Plastic injection molding machine air circuits
- Semiconductor fab equipment gas distribution
- Automated packaging line actuator clusters
Installation tip:
Apply 2-3 drops of pneumatic sealant (Loctite 545) on male threads before assembly.
Tighten to 25-30 N·m torque using crowfoot wrench for even pressure distribution.
Maximum angular deviation: ±3° from primary flow axis.
| Property | Property Value |
|---|---|
| sku | X-APX6M20 |
