Airtac X-APX Adapter - Y-Type Threaded Tee X-APX802
AirTAC X-APX802 Y-Type Threaded Tee Fitting Technical Details
- Model Series: X-APX802 (Y-Type Branch)
- Thread Standard: BSPP (G) / NPT optional
- Port Configuration: 3-way T-shaped flow path
- Port Size: 1/8" (G1/8/BSPP equivalent)
- Material: Lead-free brass with nickel plating
- Seal Material: HNBR (Hydrogenated Nitrile) for enhanced oil resistance
- Max Working Pressure: 1.5 MPa (217 psi)
- Temperature Range: -20℃ to 120℃ (continuous use)
- Burst Pressure: ≥4.5 MPa
- Surface Treatment: Electroless nickel plating (8-12μm thickness)
- Weight: 28g ±1g
- Dimensions: 40mm (L) × 24mm (W) × 24mm (H)
- Thread Engagement Depth: 8mm minimum
- Leakage Rate: ≤3 bubbles/min under 0.5 MPa air pressure
- Vibration Resistance: 10-55Hz, 1.5mm amplitude
- IP Rating: IP40 (protected against 1mm particles)
Precision-machined Y-type tee connector featuring triple-sealed threads and optimized flow channels. The 60° branch angle minimizes pressure drop while maintaining compact dimensions. Nickel plating provides corrosion resistance in humid environments. Compatible with pneumatic fluids including lubricated air, inert gases, and vacuum applications.
- Pneumatic manifold splitting in robotic arm end effectors
- Vacuum circuit distribution for pick-and-place systems
- Modular air line configurations in semiconductor handling equipment
- Multi-tool pneumatic supply in automotive assembly lines
- Medical gas line branching in dental chairs
Mounting guidance:
Apply 1.5-2 wraps of PTFE tape clockwise on male threads.
Use 8-10Nm torque for brass-to-brass connections.
Avoid overtightening - maximum 1/4 turn past finger-tight position.
- AirTAC PIS series push-to-connect fittings
- 4mm/6mm polyurethane tubing (OD tolerance ±0.1mm)
- X-SNU series tube nuts for vibration resistance
| Property | Property Value |
|---|---|
| sku | X-APX802 |
