Airtac X-APX Adapter - Y-Type Threaded Tee X-APX8M16
AirTAC X-APX Y-Type Threaded Tee Connector X-APX8M16 Technical Details
- Model: X-APX8M16
- Series: X-APX Standard Pneumatic Connector Series
- Type: Y-Type Tee with Metric Thread
- Body Material: Nickel-plated brass (C3604)
- Seal Material: NBR (Nitrile Rubber)
- Thread Standards: M16×1.5 (all three ports)
- Max Working Pressure: 1.5 MPa (15 bar)
- Proof Pressure: 2.25 MPa
- Burst Pressure: ≥3 MPa
- Operating Temperature: -20℃ to 80℃ (with NBR seals)
- Flow Rate: 750 NL/min (at 0.5 MPa pressure drop)
- Weight: ~50g (including packaging)
- Dimensions:
- Height: 34.5mm (from base to top port)
- Width: 36mm (between lateral ports)
- Depth: 28mm (front to back measurement)
- Surface Treatment: Electroplated nickel (3-5μm thickness)
- Vibration Resistance: 10-55Hz, 1.5mm amplitude
- Certifications: RoHS compliant, ISO 1179-1 standard
Precision-engineered Y-shaped pneumatic tee connector featuring triple M16×1.5 metric threads, designed for creating 90° branch connections in compact pneumatic systems. The nickel-plated brass construction ensures corrosion resistance while maintaining structural integrity under cyclic pressure loads. Optimized internal flow path reduces turbulence by 18% compared to conventional tees.
- Modular pneumatic circuit distribution in automation equipment
- Air brake system branching in commercial vehicles
- Compressed air splitting for multi-tool industrial stations
- Vacuum system junctions in packaging machinery
- Robotic actuator air supply networks
Installation recommendation:
Apply 2-3 wraps of PTFE tape on male threads and tighten to 25-30 N·m torque.
Avoid overtightening which may cause port deformation. For vertical installations,
position main flow path horizontally to prevent particulate accumulation.
| Property | Property Value |
|---|---|
| sku | X-APX8M16 |
