Airtac X-APX Adapter - Y-Type Threaded Tee X-APX8M20
AirTAC X-APX Series Y-Type Threaded Tee Fitting X-APX8M20 Technical Details
- Model: X-APX8M20
- Type: Y-shaped pneumatic tee connector with metric thread
- Thread specification: M20×1.5 (external thread both ends)
- Material: Brass (nickel-plated) / Stainless steel SS304 optional
- Pressure range: 0.05–1.5 MPa (7–217 PSI)
- Temperature range: -5℃ to 80℃ (23℉ to 176℉)
- Seal material: NBR (Nitrile) rubber O-rings
- Surface treatment: Electroless nickel plating (3-5μm thickness)
- Flow coefficient (Cv): 2.1 (at 6 bar)
- Leakage rate: ≤0.1 NL/min under max pressure
- Weight: 85g (brass version) / 120g (stainless steel)
- Dimensions: 40mm (L) × 30mm (W) × 20mm (H)
- Thread engagement depth: 10mm minimum
- Torque specification: 35–45 N·m (brass) / 55–65 N·m (stainless)
Precision-machined Y-shaped flow divider featuring triple-port configuration with 120° branch angle. The 60° tapered thread design ensures leak-free connections in high-vibration environments. Optimized internal channels minimize pressure drop (ΔP ≤0.02MPa at 1MPa input). Compatible with ISO 1179-2 standard fittings.
- Pneumatic distribution blocks in packaging machinery
- Modular assembly of automated production line manifolds
- Compressed air branching for CNC machine tool clamps
- Hydraulic test bench plumbing systems (oil-resistant version)
- Robotic arm end-effector pneumatic circuits
Installation protocol:
Apply 2-3 wraps of PTFE tape on male threads (do not overlap sealant with O-rings).
Tighten using flank-to-flank wrench contact only - avoid gripping hexagonal body.
Perform pressure test at 1.25× system pressure after installation.
| Property | Property Value |
|---|---|
| sku | X-APX8M20 |
