Airtac X-APY Connector - Y-Type Tee X-APY10
AirTAC X-APY10 Y-Type Tee Fitting Specifications
- Model: X-APY10
- Type: Y-shaped triple port pneumatic connector
- Thread standard: PT1/8 (BSPP)
- Material: Brass with nickel plating (stainless steel optional)
- Max working pressure: 1.5 MPa
- Min burst pressure: 6 MPa
- Temperature range: -20℃ to 80℃
- Seal material: NBR (HNBR available for high-temp applications)
- Weight: 24g ±1g
- Dimensions: 28mm(L) × 18mm(W) × 18mm(H)
- Flow coefficient (Cv): 0.15
- Surface treatment: Electroless nickel plating (3-5μm)
- Compliance: RoHS 2.0 compliant
Precision-engineered Y-connector featuring 120° branch angle for optimized airflow distribution in compact pneumatic systems. The chamfered internal channels reduce turbulence and pressure drop by 18% compared to standard tees. Includes integrated O-ring grooves for leak-proof connections without additional seals.
- Multi-axis robotic tool changers requiring compact flow division
- Modular pneumatic control panels with space constraints
- Medical device gas distribution systems
- Food processing equipment (specify SS316L version)
- PLC-controlled pneumatic circuits needing symmetrical flow splitting
Installation best practice:
Use two wrenches during assembly - one to hold the base fitting and another to tighten the connected component.
Apply 0.5-0.8 N·m torque maximum. Perform pressure test at 1.8 MPa for 10 minutes post-installation.
