Airtac X-APY Connector - Y-Type Tee X-APY6
AirTAC X-APY6 Y-Type Tee Fitting Technical Details
- Model: X-APY6
- Type: Triple-port Y-shaped pneumatic connector
- Thread standard: PT1/8 (BSPP)
- Material: Brass with nickel-plated finish
- Max working pressure: 1.0 MPa (145 psi)
- Temperature range: -5℃ to 80℃
- Weight: 28g ±1g
- Dimensions: 32mm(L) × 21mm(W) × 21mm(H)
- Seal material: NBR (Nitrile rubber)
- Flow rate capacity: 250 L/min (ANR)
- Surface hardness: HV200 minimum
- Corrosion resistance: 96hrs salt spray test passed
- IP rating: IP40 (non-submersible)
Precision-machined Y-shaped flow divider/combiner featuring leak-proof design with dual O-ring seals. The 120° branch angle optimizes flow distribution while maintaining compact dimensions. Compatible with pneumatic tubing OD 6mm (1/4"). Includes anti-vibration threads and tool-free installation grooves.
- Pneumatic circuit branching in automation lines
- Air tool manifold connections
- Medical device gas distribution systems
- Packaging machine actuator networks
- Laboratory pneumatic control setups
- Food processing equipment air lines
Installation guidelines:
Apply thread sealant (PTFE tape recommended) on male threads.
Tighten to 1.2-1.5 N·m torque. Avoid overtightening to prevent
port deformation. Inspect seals every 6 months in high-cycle applications.
| Property | Property Value |
|---|---|
| sku | X-APY6 |
