Airtac X-EPE Fitting - T-Type Tee X-EPE10
$3.53
Regular price
$11.03
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
X-EPE10
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC X-EPE10 Tee Fitting Specifications
- Model: X-EPE10
- Type: Precision-engineered T-type tee fitting
- Thread standard: Metric (M5×0.8) / Optional PG thread
- Port configuration: 1 input → 2 outputs (90° branch)
- Material: Brass (nickel-plated) / Stainless steel 303 optional
- Seal material: NBR (standard) / FKM available for high-temp
- Max working pressure: 1.0 MPa (10 bar)
- Min burst pressure: 3.0 MPa
- Operating temp range: -20℃ to 80℃ (NBR seals)
- Surface roughness: Ra ≤3.2μm at sealing surfaces
- Weight: 52g ±2g (brass version)
- Dimensions: 30mm(L) × 28mm(W) × 28mm(H)
- Vibration resistance: 10-2000Hz, 15G acceleration
- Certification: RoHS compliant, ISO 6150-B standard
- Color coding: Natural brass/silver (custom colors optional)
High-flow tee connector with optimized internal geometry (Φ3.5mm flow channels) for minimal pressure drop. Features anti-vibration thread design with 6-point wrench flats for tool engagement. Oxygen-cleaned versions available for medical applications.
Installation Scenarios:
- Pneumatic circuit branching in robotic end effectors
- Sensor cluster air supply distribution
- Modular assembly systems using ISO 15407-1 profiles
- Vacuum line splitting for pick-and-place units
- Cooling air distribution in laser cutting systems
Maintenance protocol:
Torque limit 1.2-1.5N·m during installation. Use thread sealant
only on male threads. For gas applications, perform helium leak
test at 0.6MPa after installation.
Optimized Pairing:
Works best with AirTAC PE-10 series tubing (ID4mm/OD6mm).
Not recommended for hydraulic fluids above ISO VG32 viscosity.
| Property | Property Value |
|---|---|
| sku | X-EPE10 |
