Airtac X-EPEG Adapter - T-Type Reducing Tee X-EPEG806
$3.32
Regular price
$10.82
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
X-EPEG806
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC X-EPEG806 T-Type Reducing Tee Fitting Specifications
- Model: X-EPEG806
- Type: T-Type Reducing Tee (Dual Diameter)
- Material: Brass with nickel plating (anti-corrosion)
- Port configuration: 1/2" (PT) → 3/8" (PT) branch reduction
- Max working pressure: 1.0 MPa (145 psi)
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Installation torque: 12-15 N·m recommended
- Seal type: Integrated O-ring (NBR standard, EPDM optional)
- Weight: 82g ±2g
- Dimensions: 46mm (L) × 34mm (W) × 29mm (H)
- Surface roughness: Ra ≤3.2μm
- Compliance: RoHS compliant
Precision-machined brass tee fitting with asymmetric port design for space-constrained pneumatic/hydraulic systems. Features 360° rotatable branch port for flexible piping arrangements. Pressure-rated for intermittent surge conditions.
Typical Applications:
- Branch line creation in compact automation equipment
- Tool changer interfaces on CNC machines
- Pressure gauge manifold connections
- Mobile hydraulic systems requiring diameter transition
- Vacuum line distribution in packaging systems
Installation protocol:
Apply 1.5-2 wraps of PTFE tape on male threads. Tighten branch port first,
then main line ports. Avoid aligning ports at exact 90° angles to prevent
stress concentration. Max vibration tolerance: 5G @ 50Hz.
Flow characteristics:
- Main line flow capacity: 120 L/min (Cv=0.15)
- Branch line flow capacity: 80 L/min (Cv=0.09)
- Pressure drop at max flow: ≤0.02 MPa
| Property | Property Value |
|---|---|
| sku | X-EPEG806 |
