Airtac X-EPEW Adapter - T-Type Reducing Tee X-EPEW1210
AirTAC X-EPEW1210 T-Type Reducing Tee Fitting Specifications
- Model: X-EPEW1210
- Type: Brass T-type reducing tee with male-female threads
- Material: Lead-free brass (CuZn39Pb3) with nickel plating
- Thread Standards: PT1/8 (G1/8) input ports × PT1/10 (G1/10) branch port
- Pressure Rating: 0.05-1.0 MPa (7-145 PSI)
- Temperature Range: -20℃ to 80℃ (-4°F to 176°F)
- Seal Material: NBR (Nitrile) O-rings
- Flow Coefficient (Cv): 0.15
- Weight: 15.2g ±0.5g
- Dimensions: 50mm(L) × 20mm(W) × 20mm(H)
- Surface Roughness: Ra ≤1.6μm on sealing surfaces
- Vibration Resistance: 10-55Hz, 1.5mm amplitude
- Certification: RoHS compliant, ISO 1179-1 standard
Precision-engineered brass tee fitting with corrosion-resistant nickel plating, designed for creating compact branch connections in pneumatic systems. Features asymmetrical port sizing (1/8"→1/10") for controlled flow distribution. The 60° angular port alignment optimizes space utilization in manifold assemblies.
- Modular pneumatic circuit distribution blocks
- Air compressor accessory line branching
- Robotic arm tool changer manifolds
- CNC machine lubrication line adapters
- Industrial vacuum system pressure balancing
Installation guidelines:
Apply 1.5-2 wraps of PTFE tape on male threads.
Use torque-limited wrench (4-6 N·m) to prevent overtightening.
Avoid axial misalignment exceeding 3° during assembly.
Compatible with Ø4mm-Ø8mm tubing when used with adapters.
| Property | Property Value |
|---|---|
| sku | X-EPEW1210 |
