Airtac X-EPH External Hex Elbow Connector X-EPH1203
AirTAC X-EPH1203 Hexagon Elbow Joint Technical Details
- Model: X-EPH1203
- Type: Reusable 90° swivel elbow (male thread)
- Thread specification: M5×0.8 external thread (ISO 262 metric)
- Material: Brass (CuZn39Pb3) with nickel-plated finish
- Operating pressure: 0.05-1.5 MPa
- Temperature range: -20℃ to 80℃
- Rotation angle: ±30° free swivel
- Seal material: NBR (Nitrile) O-ring
- Surface hardness: HV 200±20
- Protection rating: IP40 (standard dust/contact protection)
- Installation torque: 0.5-0.7 Nm (recommended with torque wrench)
- Weight: 28g ±1g
- Dimensions: 25mm(L) × 16mm(W) × 16mm(H) (hexagon profile)
Precision-machined flow connector featuring a 6-point wrench grip for secure installation in confined spaces. The chrome-plated brass construction resists galvanic corrosion while maintaining dimensional stability under cyclic stress. Sealing integrity maintained through 50,000+ rotation cycles (per ISO 6150B endurance testing). Compatible with pneumatic fluids and hydraulic oils up to ISO VG32 viscosity.
- Pneumatic valve manifold interconnections
- Robotic arm end effector plumbing
- Packaging machine air circuit distribution
- CNC tool changer pneumatic lines
- Medical device compressed air systems
Installation protocol:
Apply 2-3 drops of PTFE-based thread sealant (not included) before assembly.
Tighten using 8mm hex wrench until 15-20° past finger-tight position.
Perform pressure test at 1.25× system pressure after installation.
| Property | Property Value |
|---|---|
| sku | X-EPH1203 |
