Airtac X-EPH External Hex Elbow Connector X-EPH12M20
AirTAC X-EPH12M20 Hexagonal Elbow Joint Technical Details
- Model: X-EPH12M20
- Type: Reusable external hexagonal swivel joint
- Thread specification: M20×1.5 (male thread)
- Material: Aluminum alloy (A6061-T6) with anodized finish
- Max torque resistance: 120 N·m
- Pressure rating: 1.0 MPa (10 bar)
- Temperature range: -20℃ to 80℃
- Surface hardness: HV 400-450
- Rotational angle: ±15° adjustable
- Seal type: Integrated NBR O-ring (Shore A 70±5)
- Weight: 184±5g
- Dimensions: 62mm (L) × 36mm (W) × 36mm (H)
- Wrench flats: 27mm hex size
Precision-machined rotary joint featuring dual-bearing swivel mechanism for smooth angular adjustment in confined spaces. The hard-anodized surface provides wear resistance against particulate abrasion, while the integrated sealing groove prevents O-ring extrusion under dynamic loads. Compatible with ISO 1179-2 standard ports.
- Robotic arm end effector connections
- CNC machine tool coolant line adapters
- Packaging machinery rotary unions
- Semiconductor equipment gas delivery systems
- Hydraulic test bench pressure fittings
Installation protocol:
Apply thread sealant (LOCTITE 577 recommended) on male threads.
Tighten to 85-95 N·m torque using calibrated wrench. Perform
pressure test at 1.5× operating pressure for 5 minutes before
commissioning. Re-lubricate O-ring with PFPE grease every 2,000
operating hours.
| Property | Property Value |
|---|---|
| sku | X-EPH12M20 |
