Airtac X-EPH External Hex Elbow Connector X-EPH603
$4.67
Regular price
$12.17
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
X-EPH603
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC X-EPH603 Hex Elbow Joint Technical Specifications
- Model: X-EPH603
- Type: External hexagon elbow thread connector
- Material: Nickel-plated brass (body), PPS resin (lever)
- Thread specification: M5×0.8 female thread (other sizes available through adapters)
- Max torque resistance: 1.2 N·m
- Operating temperature: -5℃ to 80℃ (no condensation)
- Pressure rating: 0.05-1.0 MPa
- Swivel angle: 340° free rotation
- Weight: 35g ±2g
- Dimensions: 25mm(L) × 18mm(W) × 18mm(H)
- Surface hardness: HV300 (brass components)
- Vibration resistance: 10-55Hz, 1.5mm amplitude
Precision-engineered pivot joint featuring dual O-ring seals (NBR material) for leak-free pneumatic connections. The ergonomic lever design enables single-handed operation with 6mm tool clearance for maintenance. Anti-vibration teeth ensure stable positioning in dynamic applications.
Common Implementations:
- Robotic arm end effector pneumatic line routing
- CNC machine tool coolant valve connections
- Food processing equipment air line manifolds
- Semiconductor fab automation gas delivery
- Packaging machine rotary union interfaces
Installation protocol:
Apply 2-3 drops of pneumatic oil (ISO VG32) to swivel joint before initial use.
Tighten with 0.8-1.0 N·m torque using 8mm combination wrench.
Avoid overtightening - maximum deformation allowance 0.15mm.
| Property | Property Value |
|---|---|
| sku | X-EPH603 |
