Airtac X-EPHF Connector - In-Line Swivel Elbow X-EPHF10M10
AirTAC X-EPHF Series Tandem Hinge Joint Specifications
- Model: X-EPHF10M10
- Type: Tandem elbow joint with dual-axis compensation
- Thread specification: M10×1 male thread (ISO 1179 standard)
- Material: Nickel-plated brass body + stainless steel pivot
- Operating pressure: 0.05–1.0 MPa
- Temperature range: -20℃ to 150℃
- Rotation angle: ±25° axial / ±20° radial
- Leakage rate: ≤0.1 NL/min at 0.5 MPa
- Seal material: HNBR (Hydrogenated Nitrile) O-rings
- Surface hardness: HV 350±50 (pivot section)
- Weight: 48±2g
- Dimensions: 32mm(Ø) × 58mm(L) × 24mm(H)
- Protection rating: IP54 (standard configuration)
High-precision articulated joint featuring dual-axis angular compensation for precise alignment in pneumatic systems. The through-hole design maintains airflow efficiency while compensating for up to 3° installation misalignment. Anti-vibration structure prevents self-loosening under continuous oscillation.
- Multi-axis robotic arm end effectors
- High-cycle automated assembly lines
- Plastic injection molding machine ejectors
- Semiconductor wafer handling systems
- Food processing equipment with thermal cycling
Installation protocol:
Apply 3-5Nm torque during assembly. Use PTFE tape on male threads only.
For vertical mounting, install retaining clip (sold separately) to prevent
gravitational displacement. Lubricate pivot points monthly in high-cycle
applications (>500,000 cycles/month).
| Property | Property Value |
|---|---|
| sku | X-EPHF10M10 |
